TypeORM: search in relationships (ft. NestJS)

🤔 Why?

Because I didn’t want to perform a full search once I brought all the records. Since SQL is really optimized for queries. For this case, I wanted to filter some records based on their relationship attributes.

I’ll use a simple test case.

💡 First, we need two TypeORM entities

For the most simple of cases, let’s suppose we have two classes. A Pet and an Owner. A Pet will belong to only one Owner. Both entities live in the same folder.

1
// ./entities/pet.ts
2
import { Column, Entity, JoinColumn, ManyToOne, PrimaryGeneratedColumn } from 'typeorm';
3
import { Owner } from './owner';
4

5
@Entity()
6
export class Pet {
7
  @PrimaryGeneratedColumn()
8
  id: number;
9

10
  @Column({ name: 'owner_id' })
11
  ownerId: number;
12

13
  @ManyToOne(() => Owner)
14
  @JoinColumn({ name: 'owner_id' })
15
  owner: Owner;
16
}

And

1
// ./entities/owner.ts
2
import { Column, Entity, JoinColumn, OneToMany, PrimaryGeneratedColumn } from 'typeorm';
3
import { Pet } from './pet';
4

5
@Entity()
6
export class Owner {
7
  @PrimaryGeneratedColumn()
8
  id: number;
9

10
  @Column({ name: 'first_name' })
11
  firstName: string;
12

13
  @Column({ name: 'last_name' })
14
  lastName: string;
15

16
  @OneToMany(() => Pet, () => Owner)
17
  @JoinColumn({ name: 'owner_id' })
18
  pets: Pet[];
19
}

🔨 Creating the method for the controller

We will use NestJS. A simple NestJS controller seems like the following example.

1
@Controller('pets')
2
export default class AppController {
3
  @Get()
4
  async search() {
5
    // TODO: Implement search
6
  }
7
}

As you see here. The URL for the search will be /pets/search

🚛 Using Repositories

This is the method Typescript friendly. I prefer this since I’ll have type validation if I update any field in the future.

1
// ./app.ts
2
import { Controller, Get, Query } from '@nestjs/common';
3
import { Pet } from './entities/pet';
4
import { FindManyOptions, FindOptionsWhere, Like, Repository } from 'typeorm';
5
import { InjectRepository } from '@nestjs/typeorm';
6

7
@Controller('pets')
8
export default class AppController {
9
  constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}
10

11
  @Get('/repository')
12
  async searchUsingRepository(@Query('search') search?: string) {
13
    // By default we load the relationship in the default options
14
    const options: FindManyOptions<Pet> = { relations: { owner: true } };
15

16
    if (search?.length) {
17
      // if search request query param was sent. Create an array of words
18
      const searchFormattedText = search.trim().split(' ');
19
      const where: FindOptionsWhere<Pet>[] = [];
20

21
      // Create OR WHERE queries by each word into first and last name
22
      for (const word of searchFormattedText) {
23
        where.push({ owner: { firstName: Like(`%${word}%`) } });
24
        where.push({ owner: { lastName: Like(`%${word}%`) } });
25
      }
26

27
      // Adding those where to options
28
      options.where = where;
29
    }
30

31
    const pets = await this.petRepository.find(options);
32

33
    return { pets };
34
  }
35
}

It will produce the following query

1
SELECT `Pet`.`id`                    AS `Pet_id`,
2
       `Pet`.`owner_id`              AS `Pet_owner_id`,
3
       `Pet__Pet_owner`.`id`         AS `Pet__Pet_owner_id`,
4
       `Pet__Pet_owner`.`first_name` AS `Pet__Pet_owner_first_name`,
5
       `Pet__Pet_owner`.`last_name`  AS `Pet__Pet_owner_last_name`
6
FROM `pet` `Pet`
7
         INNER JOIN `owner` `Pet__Pet_owner` ON `Pet__Pet_owner`.`id` = `Pet`.`owner_id`
8
WHERE ((`Pet__Pet_owner`.`first_name` LIKE ?) OR (`Pet__Pet_owner`.`last_name` LIKE ?))

🚛 Using Query Builder from repositories

This method is more close to SQL. Useful if you’re more comfortable with it.

1
// ./app.ts
2
import { Controller, Get, Query } from '@nestjs/common';
3
import { Pet } from './entities/pet';
4
import { Brackets, SelectQueryBuilder, Like, Repository } from 'typeorm';
5
import { InjectRepository } from '@nestjs/typeorm';
6

7
@Controller('pets')
8
export default class AppController {
9
  constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}
10

11
  @Get('/querybuilder')
12
  async searchUsingQueryBuilder(@Query('search') search?: string) {
13
    // This is how we load relationships here
14
    let query = this.petRepository.createQueryBuilder('p').innerJoinAndSelect('p.owner', 'o');
15

16
    if (search?.length) {
17
      // By default we load relationship in the default options
18
      const searchFormattedText = search.trim().split(' ');
19

20
      // With query builder we specify the AND or OR queries
21
      // Brackets is a way to group queries within a ( )
22
      query = query.andWhere(
23
        new Brackets((queryPart: SelectQueryBuilder<Pet>) => {
24
          for (const word of searchFormattedText) {
25
            queryPart.orWhere('o.first_name like :firstName', {
26
              firstName: `%${word}%`,
27
            });
28
            queryPart.orWhere('o.last_name like :lastName', {
29
              lastName: `%${word}%`,
30
            });
31
          }
32
        }),
33
      );
34
    }
35

36
    const pets = await query.getMany();
37

38
    return { pets };
39
  }
40
}

The query for the function above will result as

1
SELECT `p`.`id`         AS `p_id`,
2
       `p`.`owner_id`   AS `p_owner_id`,
3
       `o`.`id`         AS `o_id`,
4
       `o`.`first_name` AS `o_first_name`,
5
       `o`.`last_name`  AS `o_last_name`
6
FROM `pet` `p`
7
         INNER JOIN `owner` `o` ON `o`.`id` = `p`.`owner_id`
8
WHERE (`o`.`first_name` like ? OR `o`.`last_name` like ?)

⭐ Final result

This is the final controller. I’ll add a docker-compose file if you want to try it by yourself. Also, there is a /fake method to create records if you want to test the search.

Remember, this is ONLY the main controller. Check my FULL demo on Github here

1
// ./app.ts
2
import { Controller, Get, Post, Query } from '@nestjs/common';
3
import { Pet } from './entities/pet';
4
import {
5
  Brackets,
6
  FindManyOptions,
7
  FindOptionsWhere,
8
  InsertResult,
9
  Like,
10
  Repository,
11
  SelectQueryBuilder,
12
} from 'typeorm';
13
import { InjectRepository } from '@nestjs/typeorm';
14
import { Owner } from './entities/owner';
15

16
@Controller('pets')
17
export class AppController {
18
  constructor(
19
    @InjectRepository(Pet) private petRepository: Repository<Pet>,
20
    @InjectRepository(Owner) private ownerRepository: Repository<Owner>,
21
  ) {}
22

23
  @Get('/repository')
24
  async searchUsingRepository(@Query('search') search?: string) {
25
    const options: FindManyOptions<Pet> = { relations: { owner: true } };
26

27
    if (search?.length) {
28
      const searchFormattedText = search.trim().split(' ');
29
      const where: FindOptionsWhere<Pet>[] = [];
30

31
      for (const word of searchFormattedText) {
32
        where.push({ owner: { firstName: Like(`%${word}%`) } });
33
        where.push({ owner: { lastName: Like(`%${word}%`) } });
34
      }
35

36
      options.where = where;
37
    }
38

39
    const pets = await this.petRepository.find(options);
40

41
    return { pets };
42
  }
43

44
  @Get('/querybuilder')
45
  async searchUsingQueryBuilder(@Query('search') search?: string) {
46
    let query = this.petRepository.createQueryBuilder('p').innerJoinAndSelect('p.owner', 'o');
47

48
    if (search?.length) {
49
      const searchFormattedText = search.trim().split(' ');
50

51
      query = query.andWhere(
52
        new Brackets((queryPart: SelectQueryBuilder<Pet>) => {
53
          for (const word of searchFormattedText) {
54
            queryPart.orWhere('o.first_name like :firstName', {
55
              firstName: `%${word}%`,
56
            });
57
            queryPart.orWhere('o.last_name like :lastName', {
58
              lastName: `%${word}%`,
59
            });
60
          }
61
        }),
62
      );
63
    }
64

65
    const pets = await query.getMany();
66

67
    return { pets };
68
  }
69

70
  @Post('/fakes')
71
  async fakes() {
72
    const ownerPromises: Promise<InsertResult>[] = [];
73
    let ownerCount = await this.ownerRepository.count();
74

75
    for (let i = ownerCount + 1; i <= ownerCount + 100; i++) {
76
      const owner = new Owner();
77
      owner.firstName = `first_${i} name_${i}`;
78
      owner.lastName = `last_${i} name_${i}`;
79
      ownerPromises.push(this.ownerRepository.insert(owner));
80
    }
81

82
    await Promise.all(ownerPromises);
83

84
    ownerCount = await this.ownerRepository.count();
85

86
    const petPromises: Promise<InsertResult>[] = [];
87
    let petCount = await this.petRepository.count();
88

89
    for (let j = petCount + 1; j <= petCount + 100; j++) {
90
      const pet = new Pet();
91
      pet.ownerId = this.#randomInteger(1, ownerCount);
92
      petPromises.push(this.petRepository.insert(pet));
93
    }
94

95
    await Promise.all(petPromises);
96

97
    petCount = await this.petRepository.count();
98

99
    return { ownerCount, petCount };
100
  }
101

102
  #randomInteger(min: number, max: number) {
103
    min = Math.ceil(min);
104
    max = Math.floor(max);
105
    return Math.floor(Math.random() * (max - min) + min);
106
  }
107
}
